Camera Image Sensor:-1/3" Progressive Scan CMOS

Max. Resolution:-2560 × 1440

Min. Illumination:- Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR

Shutter Time:- 1/3 s to 1/100,000 s

Day & Night:- IR cut filter

Angle Adjustment:- Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°

Lens Lens Type:- Fixed focal lens, 2.8 and 4 mm optional

Focal Length & FOV:- 2.8 mm, horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114°

4 mm, horizontal FOV 78°, vertical FOV 42°, diagonal FOV 93°

Lens Mount:- M12

Iris Type:- Fixed

Aperture:- F1.6

Video Main Stream:- 50 Hz:20 fps (2560 × 1440)25 fps (1920 × 1080, 1280 × 720)60 Hz:20 fps (2560 × 1440)24 fps (1920 × 1080, 1280 × 720)

Sub-Stream:- 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)

Video Compression:- Main stream: H.265+/H.265/H.264+/H.264,

Sub-stream: H.265/H.264/MJPEG

Video Bit Rate:- 32 Kbps to 8 Mbps

Audio Audio Type:- Mono sound

Environment Noise Filtering:- Yes

Audio Sampling Rate:- 8 kHz/16 kHz

               Audio Compression:- G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC

Audio Bit Rate:-64 Kbps (G.711 ulaw)/64 Kbps (G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64      Kbps (AAC-LC)

Network Security:- Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest    authentication for Open Network Video Interface, security audit log, host authentication (MAC address)

Simultaneous Live View:-Up to 6 channels

API:- Open Network Video Interface (Profile S, Profile T, Profile G (only -F model supports)),ISAPI,SDK

Protocols:- TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP

User/Host:- Up to 32 users

      3 user levels: administrator, operator, and user

Image Wide Dynamic Range (WDR):- 120 dB

SNR:- ≥ 52 dB

Day/Night Switch:- Day,Night,Auto,Schedule

Image Enhancement:- BLC,HLC,3D DNR

Image Settings:- Rotate mode,saturation,brightness,contrast,sharpness,gain,white                                                                                    balance,adjustable by client software or web browser

Privacy Mask:- 4 programmable polygon privacy masks
