Camera Image Sensor:- 1/3" Progressive Scan CMOS

Max. Resolution:- 2560 × 1440

Min. Illumination:-Color: 0.01 Lux @ (F2.0, AGC ON),B/W: 0.005 Lux @ (F2.0, AGC ON),0 Lux with light

Lens Focal Length:- 2.8 mm, 4 mm

FOV:-2.8 mm, horizontal FOV 94°, vertical FOV 49°, diagonal FOV 114°

  4 mm, horizontal FOV 70°, vertical FOV 35°, diagonal FOV 85°

Aperture:- F1.6

Video Main Stream:- 50 Hz: 20 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

  60 Hz: 20 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

Sub-Stream:- 50 Hz: 25 fps (640 × 480, 640 × 360)

Video Compression:- H.265, H.264, MJPEG

Video Bit Rate:- 32 Kbps to 8 Mbps

H.264 Type:- Baseline profile, Main profile, High profile

H.265 Type:- Main profile

Audio Audio Compression:- G.711/G.722.1/G.726/MP2L2/PCM//AAC-LC

Audio Bit Rate:- 16 Kbps (G.722.1)/64 Kbps (G.711)/32 to 192 Kbps (MP2L2)/16 Kbps (G.726)/16 to 64 Kbps (AAC-LC)/8 to 48 Kbps (PCM)

Audio Sampling Rate:- 8 kHz,16 kHz

Environment Noise Filtering:- Yes

Network Protocols:- IPv4/IPv6, HTTP, HTTPS, QoS, FTP, SMTP, UPnP, DNS, NTP, RTSP, RTP, TCP/IP, UDP, DHCP, Bonjour

API:- ONVIF (Profile S, Profile G, Profile T),ISAPI,SDK

Image Image Settings:- Saturation, brightness, contrast, and sharpness adjustable by client software or web browser

Wide Dynamic Range (WDR):- Digital WDR

Image Enhancement:- BLC, HLC, 3D DNR
